Trailed Round Baler Wrapper

The MF TW 130 and MF TW 160 are easy to use straightforward wrappers with a grid frame and exceptionally low wrapping table.

Key Benefits

Film Overlap

Film Overlap

The correct film overlap is ensured by the ratio of bale rotation speed and the speed of the wrapping table. The guides on the wrapping table make sure that the bale remains firmly positioned in the centre of the table.

MF TW Arms

MF TW Arms

The MF TW 130 and MF TW 160 are easy to use straightforward wrappers with a grid frame and exceptionally low wrapping table. They’re equipped with a strong, welded loading arm that can be adjusted between 0.9m and 1.60m. The arm can lift bales up to 1.30m diameter (max. 1000kg) for the MF TW 130 and up to 1.60m diameter (max. 1250kg) for the MF TW 160.

Adjustable Film Layers

Adjustable Film Layers

Depending on the crop and conditions, the operator can easily adjust the required number of film layers. The pre-stretching device is designed to work with 500mm or 750mm rolls and can be set at 55% or 70% stretch for tighter wrapping and reduced film consumption. A quick-lock system makes the replacement of empty rolls fast and easy. Storage positions provide the facility to carry up to 3 extra rolls of film.

Bale Discharge

Bale Discharge

Bale discharge is exceptionally gentle, without the risk of damaging the wrapped bale or the ground, thanks to a lowpositioned wrapping table which tilts close to the ground when unloading bales.

Transport

Transport

On the MF TW 130 the right-hand side transport wheel can be turned around the centre spindle, extending the overall transport width from only 2.30m to 2.85m, thus increasing the overall wrapper stability. As an additional function, the MF TW 130 & MF TW 160 wrappers can be used to transport one or two pre-wrapped bales from the field.

Technology & Innovation

Transport Wheel

Transport Wheel

On the MF TW 130 the right-hand side transport wheel can be turned around the centre spindle, extending the overall transport width from only 2.30m to 2.85m, thus increasing the overall wrapper stability.

Welded Loading Arm

Welded Loading Arm

MF TW 130 and MF TW 160 are equipped with a strong, welded loading arm that can be adjusted between 0.9m and 1.60m. The arm can lift bales up to 1.30m diameter (max. 1,000kg) for the MF TW 130 and up to 1.60m diameter (max. 1,250kg) for the MF TW 160.

Transport Pre-Wrapped Bales

Transport Pre-Wrapped Bales

MF TW 130 & MF TW 160 wrappers can be used to transport one or two pre-wrapped bales from the field.

Bale Discharge System

Bale Discharge System

The MF TW 160 is fitted with a width adjustable active bale discharge system. When the bale is tipped off the wrapping table the discharge table lifts to catch the bale and gently lowers it to the ground, eliminating any film damage.

Gentle Bale Discharge

Gentle Bale Discharge

Bale discharge is exceptionally gentle, without the risk of damaging the wrapped bale or the ground, thanks to a low-positioned wrapping table which tilts close to the ground when unloading bales.

Optional Bale Tipper

Optional Bale Tipper

An optional baler tipper is available to prevent the bales from rolling in hilly conditions, improving safety and reducing by up to 15% the time required for transport/loading and for bale collections in the field.

Film Layers

Film Layers

The operator can easily adjust the required number of film layers. The pre-stretching device is designed to work with 500mm or 750mm rolls and can be set at 55% or 70% stretch for tighter wrapping and reduced film consumption.

Film Storage

Film Storage

A quick-lock system makes the replacement of empty rolls fast and easy. Storage positions provide the facility to carry up to 3 extra rolls of film.

Film Overlap

Film Overlap

The correct film overlap is ensured by the ratio of bale rotation speed and the speed of the wrapping table. The guides on the wrapping table make sure that the bale remains firmly positioned in the centre of the table.

E-Link Plus

E-Link Plus

The MF TW 160 is equipped with the ‘E-link Plus’ control box. This easy to use system allows semi-automatic or fully automatic control of the wrapper. The complete process from loading through to discharge is controlled with minimum effort.

MF TW 130 Controls

MF TW 130 Controls

The MF TW 130 is equipped with very simple semi-automatic controls, for fast and reliable trouble-free operation.

Available Models

Model

Control

Bale Diameter (m)

Approximate weight (kg)

MF TW 130 Semi-Automatic 0.9 - 1.3 1,080
MF TW 160 Automatic 0.9 - 1.6 2,110
