Designed to offer choice for farmers
The new Massey Ferguson Activa S combine range has features for performance and practicality. The operator has been given new higher levels of comfort in this class while offering simple straightforward choices of specification.
Medium to large farmers often have a variety crops to combine and each machine needs to offer the best selection of settings to get the output required with a good clean sample. Surveys show that the operators of these machines need practical solutions to do this and value simplicity and comfort.
Simple parallel linkage makes for effortless change of angle in the field. Both the MF 7345 and MF 7347 are available as a ParaLevel version, this patented system offers levelling with the table on slopes up to 20% (4WD). Combine components are generally designed to work on the level. This system maintains that level longer on slopes and therefore keeps the machine working at maximum efficiency for longer - increasing your output. Part of the package for balance is a standard 4WD system (2WD option), this gives more positive steering control and greater traction in all conditions, making it a safer place for your operator to work.
Introducing the Proline Cab
An excellent cab environment is the key to getting the best performance from the machine and operator. Excellent visibility with ergonomically placed controls makes the workload easier and more productive. Intuitive menus on the TechTouch 2 terminal provide information at a moment's notice and active warning systems protect your investment.
How much importance do you place on your combine engine?
We can promise you that your AGCO POWER engine has been designed to match the latest emission regulations using third generation SCR technology meaning that it actually has one of the most advanced designs on the market. It's better for the environment and running costs will be one of the lowest in the business. These are important parameters.
MCS (Multicrop Separator)
The MCS (Multicrop Separator) has one unique feature that sets it apart from the rest, the ability to rotate the concave up over the top of the rotary separator when it is not required. The MCS concave is moved electrically, requiring no tools. This makes it possible to optimise machine performance in dry conditions reducing the load on the shaker shoes and considerably improving the straw quality.
The grain tanks have a high capacity of 8,600 litres, while the unloading rate of 105 l/sec (MCS) is fast for quick unloading. The turret auger can cope with the highest of trailers in the field or on the road. An optional yield monitor and moisture sensor - the Ceres 8000i with integral SD card reader - can be fitted.
Technology & Innovation
A full range of MF CornFlow™ headers are available to suit your Massey Ferguson combine harvester, offering 6 or 8 row with 70cm or 75cm row spacings in rigid or folding formats.
With cutting widths from 4.2 m – 7.6 m, the Freeflow™ table features a welded frame to which bolt-on panels (such as the table bottom plates) are mounted, making it extremely easy to replace parts when necessary.
PowerFlow™ is the industry benchmark table for high capacity in all conditions. The proven belt drive powers the crop into the combine ensuring seamless feeding.
Power Feed Roller
The Power Feed Roller (MCS Version only) at the front of the main crop elevator gives a consistent crop flow from the table into the main crop elevator. It can be reversed simply and effectively from the cab.
Optional Rape Auger
The optional rape auger for the PowerFlow table increases the flow of tall crops into the elevator thereby increasing the output considerably. Two electrical side knives complete the rapeseed kit.
Full Width Auger Fingers
Full width auger fingers on the Freeflow™ table increase auger throughout, ensuring positive and fast feed into the main crop elevator.
The knife is a massive 1.14 m from the table auger, so vision and performance are optimum. The rugged PowerFlow™ belts power the crop away from the knife and into the main crop elevator at a consistent speed.
CornFlow - Technopolymer Snouts
The Technopolymer snouts are light, hard wearing, low profile and have replaceable anti wear plates for long life.
Schumacher Knife - FreeFlow Table
The Schumacher knife is the best performing knife in the business at 1,254 cuts a minute. Self-cleaning and consistently sharp, this keeps the crop moving in tough conditions.
TerraControl II provides a mix of automatic functions for the standard table-levelling (FreeFlow™ or PowerFlow™), ground-following system (Field pressure) and headland management – all the metrics are controlled from the operator’s multifunction lever.
A twin rotor multi adjustable chaff spreader is available. Electrical deflectors for the straw chopper are available as an option, which allows the straw to be directed from the uncut crop if required.
Multicrop Separator - MCS
The MCS provides a massive separation area to remove as much grain as possible before it reaches the walkers. The MCS has the ability to rotate the concave over the top of the rotary separator when it is not required.
The long straw walkers feature four steps with ‘active walls’. The 21 cm high, vertical sections of the walker steps are made up of permeable grids. The front steps of the straw walkers are reinforced for maize.
The straw chopper is specifically designed to provide chopping and spreading performance suitable for farmers using reduced tillage operations. The knives are serrated to give a clean chop and reduce the power requirement.
The sieve profile is the key to shaker shoe performance. The high performance sieves are specially designed with vertical tags which improve the sample and allow you to open the sieves wider for greater throughput.
8600 Litre Grain Tank
The grain tanks have a high capacity of 8,600 litres, while the unloading rate of 105 l/sec is fast for quick unloading. The turret auger can cope with the highest of trailers in the field or on the road.
The threshing drum has added weight in the form of ballast bars to increase the inertia behind the rasp bars as they thresh the heads. This reduces load on the drives, power requirement and fuel consumption.
The concave has differentiated wire spacing, and the rear section of the concave has half as many wires as the front section. This principle provides the optimum balance between high threshing capacity and good grain flow through the concave.
NEW ParaLevel System
Simple parallel linkage makes for effortless change of angle in the field. Both the MF 7345 S MCS and MF 7347 S MCS are available as a ParaLevel version, this patented system offers leveling with the table on slopes up to 20% (4WD) and 15% (2WD).
Rice Cylinder - Concave Version
A special Rice cylinder / concave version can be ordered with unique peg and tooth design, specifically for separation in tough conditions.
The membrane keypad is located directly on the right side of the armrest and is used to operate the principle combine functions. The soft, raised keys lead directly to the individual menus on the TechTouch 2 terminal.
The right-hand armrest is the central operating unit where the key engagement switches sit with the throttle control. Designed with a large soft pad to cushion the arm during a long day allows for maximum comfort.
TechTouch 2 Terminal
Perfectly in view and reach is the TechTouch 2 terminal which provides all the relevant performance information for setting the combine. The touch screen controls with clear definition are easy to use and adjust.
The new control interface for the operator falls naturally to hand – the PowerGrip multifunction lever sits on top of the armrest which houses all the switches for the commonly used controls.
Night Working Package
Night working package includes H9 high intensity lights for all-round excellent visibility late into the evening.
AGCO POWER ENGINE
We can promise you that your AGCO Power engine has been designed to match the latest emission regulations using SCR technology meaning that actually it has one of the most advanced designs on the market.
AGCO POWER ENGINE PERFORMANCE
Fuelling is designed to give a flat torque curve, required to give a constant delivery under load despite the conditions. This coupled with the low friction drives will give you incredibly low fuel consumption per tonne and excellent fuel economy.
One Piece Panels
One piece panels with lights allow for quick inspection access with lights for night work.
Easy refueling - both tanks are located next to each other for easy access.
Ladder rail makes inspection easy and safe.
Safe and simple access for radiator cleaning.
Max Power (hp)*
Grain Capacity (l)
Unloading speed (l/s)
Max cutting width (m)
|MF Activa S 7345||260||8,600||105||7.6||AGCO Power 6 cylinder, 7.4 Litre|
|MF Activa S 7345 MCS||260||8,600||105||7.6||AGCO Power 6 cylinder, 7.4 Litre|
|MF Activa S 7345 MCS ParaLevel||260||8,600||105||7.6||AGCO Power 6 cylinder, 7.4 Litre|
|MF Activa S 7347||306||8,600||105||7.6||AGCO Power 6 cylinder, 7.4 Litre|
|MF Activa S 7347 MCS||306||8,600||105||7.6||AGCO Power 6 cylinder, 7.4 Litre|
|MF Activa S 7347 MCS ParaLevel||306||8,600||105||7.6||AGCO Power 6 cylinder, 7.4 Litre|
|* All MF Activa S 7347 data includes 30 hp boost.|
