Mounted No-Till Planters

The MF 100 series planters are available in two specifications Economy Plus and High Spec. These tough three-point mounted machines for use on small to medium sized farms.

These planters ensure accurate fertiliser replacement, consistent depth, effective performance and maximum productivity.

Key Benefits

These robustly built, three-point mounted machines are designed for the small-to-medium scale farming operations and are available in two and four rows configurations. The Economy Plus version has a lower specification than the high specification version.

Robust 375mmØ trash coulters ensure effective performance even in the most demanding crop residues, working in front of shear-bolt protected tine fertilizer opener for accurate fertilizer placement.

Row spacing is easily varied between 45cm and 91cm to allow different crop types to be planted using different row width. The MF 104 2-4 rows No-Till Mounted Planters with large capacity seed (25kg) and fertilizer (80kg) hoppers maximize productivity throughout the planting period.

Durable 350mm double-disc seed openers, with parallel linkage, and the rubber gauge wheels (cast-iron on the economy plus) combine to provide perfect seed placement and consistency of depth.

A wide walk board with handrail and anti-slip floor covering is an additional safety feature on the MF 100, while an auto-reset fertilizer opener can also be specified.

Available Models

Model

Maximum Seed capacity (kg)

Maximum Fertiliser capacity (kg)

Row spacing minimum (m)

Row spacing maximum (m)

Maximum Working Width (m)

MF 104 Emerging Farmer Planter - 2 Rows 50 - 0.4 1.35 1.35
MF 104 - 2 Rows 50 160 0.4 1.35 1.35
MF 104 - 4 Rows 100 320 0.4 0.525 1.575
Only available in selected markets. Please check with your local Massey Ferguson Dealer or Distributor.
