The new generation of Massey Ferguson front loaders

If you need a robust, reliable loader to complement your Massey Ferguson tractor then you don’t need to look far. MF tractors with MF FL loaders are the ultimate combination of rugged ability, productivity and reliability.

Full integration of tractor and loader is achieved with the MF FL loader and Massey Ferguson tractors range. All the models are offered with 'parallel' linkage equipped as standard with a third function as an option.

The industry-leading hydraulic quick coupling is included as standard.

Your Next Steps

Key Benefits

Design

Design

From the strength and security of the subframe to the slim yet robust design of the welded box section beams, MF FL Series loaders deliver industry-leading features that ensure maximum output and dependability from your Massey Ferguson loader tractor.

Visibility

Visibility

All pipes and hoses are protected in the loader arm to improved visibility and protect the loader from dirt accumulation.

Mounting and Removing

Mounting and Removing

Fast hydraulic coupling of tractor and loader is made easy by compact hydraulic connection, the ‘Hydroquick’ or MC4. MC4 multicouplers are available as standard.

Technology & Innovation

From the strength and security of the subframe to the slim yet robust design of the welded box section beams, MF FL Series loaders deliver industry-leading features that ensure maximum output and dependability from your Massey Ferguson tractor.
Strengthened Subframes

Strengthened Subframes

Subframes are available to fit most tractors in the Massey Ferguson range and now have larger loadbearing surfaces to strengthen their already robust construction and meet the demands of today’s high-performance tractors.

Strong Double C section loader beam

Strong Double C section loader beam

Loader beam design combines strength and excellent forward visibility, with the highest quality ‘twin C-section’ steel construction.

Protected and Concealed Hydraulic Hoses

Protected and Concealed Hydraulic Hoses

Loader beam design combines strength and excellent forward visibility neatly concealing and protecting all hydraulic hoses.

Consistency in Construction

Consistency in Construction

Robotized welding ensures consistency in construction. The steel undergoes proper preparation and priming before a tough and durable powder paint finish is applied.

High on productivity... low on down-time. Serviceability, low maintenance and ease-of-use of both tractor and loader has been a key consideration in the design and construction of the MF FL series, making things simple, quick, easy and highly efficient.
Clic-On

Clic-On

When an implement is detached, the ‘Clic-on’ device holds the locking pins in their retracted position. Attaching an implement and rolling back the tool carrier allows the locking pins to return to their locked position, automatically.

Lock and Go System

Lock and Go System

All loaders are designed with the standard ‘Lock & Go’ system. Requiring no tools and incorporating rigid support legs, the ‘Lock & Go’ system is simply designed to save time, enabling straightforward attachment/detachment.

Fast Hydraulic Coupling

Fast Hydraulic Coupling

Fast hydraulic coupling of tractor and loader is made easy by compact design connections. For faster hydraulic connection, the ‘Hydroquick’ or MC4 multicouplers are available as an option.

Precise Self-Levelling

Precise Self-Levelling

These parallel lifting loaders automatically control your implement angle throughout the lifting range. This is particularly useful in keeping pallet fork level.

Easy Servicing

Easy Servicing

Outward-facing grease points easily accessible and covered.

MF FL Series loaders set the standard in control and ergonomics, ensuring simple and effective operation, leading to higher levels of comfort, safety and output. You’ll never have a more efficient tractor/loader combination.
Power Control

Power Control

The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shift between forward/reverse ranges as well as select neutral, leaving the right hand free.

SoftDrive Suspension

SoftDrive Suspension

Stresses on loader and tractor, as well as the operator, can be reduced by the optional addition of the innovative ‘SoftDrive’ shock absorption system.

LED Worklights

LED Worklights

An optional set of LED worklights is available to give you maximum visibility at night. They’re perfectly integrated in to the beam and will provide maximum productivity and vision for longer working days.

The MF FL Series can be fitted as standard with a Euro tool carrier making it possible to fit a wide variety of attachments for the job in hand.
MF FL-Companion

MF FL-Companion

This new dealer fit option provides information on: Weighing System, Position Monitoring, Weight/Cycle Total Counters, Service/Diagnostics and Loader Lights Controls.

Available Models

Model

Type

Maximum Lift height (m)*

Max lift capacity at full height (kg)**

MF FL.3619 Parallel 3.55 1,850
MF FL.3819 Parallel 3.79 1,930
MF FL.4121 Parallel 4.06 2,090
MF FL.4327 Parallel 4.25 2,680
MF FL.4628 Parallel 4.6 2,780
* Measured at Pivot Pin | ** To 1.5m height - at Pivot Pin

Implements

This comprehensive range of bale handling implements has been thoughtfully designed to provide safe, efficient and reliable operation through the complete spectrum of bale handling and distribution tasks, from field to yard.
Round Bale Spike

Round Bale Spike

Flexigrip

Flexigrip

Unigrip

Unigrip

Square Bale Fork

Square Bale Fork

Square Bale Fork - Safety

Square Bale Fork - Safety

Pallet forks can be specified with different dimensions and capacities The upper profile is manufactured in one piece and is able to be adjusted laterally to suit the load. This provides a very stable fork with immense strength.
Pallet Forks

Pallet Forks

Pallet Forks - Variation 2

Pallet Forks - Variation 2

Pallet Forks - Variation 3

Pallet Forks - Variation 3

Pallet Forks - Variation 4

Pallet Forks - Variation 4
