The ultimate tractor in your field
The new MF 7S incorporates the very latest technology to set new standards in ease of operation and reliability, to provide the user with the ultimate in efficiency while reducing operating costs.
Specifically designed to meet the needs of farming professionals, whatever your business and operations, the MF 7S is ideally suited for use in a range of applications from mixed farming to arable and contracting businesses.
Available with a wide choice of engine capacities, transmissions, cab specifications, hydraulics and PTO options, you can tailor your MF 7S to precisely match your needs.
Key Benefits
Technology & Innovation
AGCO Power Engine
6.6-litre, 6-cylinder AGCO Power engines employ Massey Ferguson’s exclusive, most advanced ‘All-In-One’ system to meet strict emission regulations.
Power Control
The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shuttle between forward/reverse, shift Dynashift speeds and ranges and select neutral, leaving the right hand free.
DYNA-6
Delivering class-leading dynamic performance and reliability, the semi-powershift transmission consists of six Dynashift ratios, optimally stepped in four ranges and changed without recourse to the clutch pedal.
Dyna-VT
Stepless transmission brings complete operator comfort and optimum fuel efficiency at all times. New Automatic mode enables operators to adjust forward speed, while automatically regulating engine speed according to load and speed.
ENGINE POWER MANAGEMENT - 30 HP BOOST
These tractors have the considerable benefit of Engine Power Management (EPM), which gives the capability of up to a 30hp-plus power boost, plus extra torque, whenever that bit extra is needed.
AIRFLOW SYSTEM
A optimised airflow system improves engine cooling, which increases performance and boosts efficiency.
MULTIPAD - CONTROL AT THE PALM OF YOUR HAND
As standard on Efficient and Exclusive, the Multipad lever operates the transmission as well as controlling cruise control, the rear linkage, PTO, headland management, spool valves through the integrated mini-joystick.
Automatic mode
Taking automatic care of up and downshifting to maximise versatility and output. Response point is adjustable according to desired engine rpm parameters.
BRAKE TO NEUTRAL
Brake to Neutral switch (Option) simultaneously operates the clutch as soon as the brake pedal is pressed. This eases the load on the operator, while increasing efficiency and convenience and is particularly useful for loader operations.
SUPERCREEP
Close control in specialist low-speed tasks is assured with additional supercreep gears, enabling forward speeds as low as 100m/hr to be achieved.
Super ECO
Standard Super Eco feature helps cut costs, with maximum speed achieved at a very low engine speed to save fuel (40km/h @ 1,500rpm, 50km/h @ 1,800rpm, depending on tyres).
HIGH CAPACITY REAR LINKAGE
Offering a capacity of up to 9,600kg the linkage can be equipped with up to five spool valves, which come with decompression levers for easy removal.
INDUSTRY-LEADING ELECTRONIC LINKAGE CONTROL (ELC)
ELC provides precise and responsive control of draft functions to accurately maintain the working depth for soil-engaging implements, as well as the position of mounted equipment.
Accurate Draft Control
MF’s digital ELC system gives the highest standards of draft control with more accurate depth settings and better ground contour following.
Hydraulic flow on Dyna-6
MF 7S tractors specified with Dyna-6 Super Eco transmissions are equipped with a 110 litre/min load-sensing hydraulics as standard and an optional 150 litre/min.
LOAD SENSING HYDRAULIC SYSTEM
The MF 7S provides a load sensing hydraulic system as standard, delivering 110 lit/min, 150 lit/min or 190 lit/min. Each capacity combines high output with low fuel requirement.
Spool valve options
A wide choice of spool valves and control options help you make the most of using modern implements as well as easing operation. Depending on your tractor’s specification, you can specify up to eight spool valves to meet all your requirements.
Essential Models
Essential versions have straightforward mechanical spool valve control, with the option of a comfortable dedicated joystick for precise loader operation.
Efficient Models
Efficient models come with the new Multipad lever, with micro joystick operation of the 1st & 2nd spool valves. These work in combination with mechanically-operated levers for the 3rd & 4th spool valves.
Exclusive Models
Exclusive version operators benefit from a new Multipad with micro joystick and two fingertips on console.
Hydraulic flow on Dyna-VT
For a dynamic hydraulic response, MF 7S Dyna-VT models are equipped with a 110 litre/min closed-centre load-sensing system as standard.
Front Linkage
Up to 4,000 kg lift capacity. A heavy duty Integrated Front Linkage System (IFLS) is available as an option and is designed to match the front suspension.
A wide choice of PTO Options
A wide choice of PTO options are available with standard PTO speeds delivered at 2,000 engine rpm – its maximum power rating and all benefit from a ‘constant power’ band of up to 1,500rpm.
Front PTO System
1,000 RPM front PTO is available. Combined with the front linkage, it allows a wide range of additional implements to be powered: reducing passes and improving efficiency.
2.88M WHEELBASE
The long wheelbase – 2.88m – ensures superior traction, while optimal weight distribution of very nearly 50:50 provides reassuring stability.
Quadlink2 Suspension System
All models benefit from the Quadlink2 suspension, boosting both comfort levels for the operator and overall machine manoeuvrability. The combination of two cylinders and three accumulators delivers an extremely comfortable ride for the operator.
CONTINUOUS DAMPING CONTROL
The ingenious Continuous Damping Control (CDC) employs a pair of active mechanical dampers that constantly monitor to provide ride comfort, taking account of driving conditions.
ACTIVE TRANSPORT CONTROL
When driving across the headland or transporting heavy mounted equipment, implement ‘bounce’ can occur. Active Transport Control is a shock absorbing system which minimises the ‘pitching’ action – automatically adjusting for different implement weights.
SPEEDSTEER
Reduces operator effort and provides faster turns. It enables the operator to adjust the steering ratio and select the number of turns of the steering wheel required for a given amount of steering angle turns.
Manoeuvrability
Great manoeuvrability helps improve productivity when turning on the headland in the field as much as it does for loader operations or negotiating narrow roads.
BALLASTING FOR FLEXIBILITY
To deal with intensive traction work or counter ballast (front/rear), sometimes you need extra weight, so a wide choice of ballasts is available. The MF 7S is available from the factory with additional front and rear weights to exactly match your needs.
Wide choice of tyres
All models are available with a wide choice of 42 inches tyres for the best traction capacity while minimising soil compaction.
Gross Vehicle Weight
MF 7S can have a Gross Vehicle Weight up to a market-leading 14 tonnes.
Ergonomics
Operators will find everything they need carefully arranged to make driving a pleasure. The new armrest, which moves with the seat, offers easy access to all the main functions including quick and convenient controls for the Bluetooth phone and radio.
New Dashboard
Operators will appreciate the slim new dashboard. This clearly displays operating data on its 70mm x 52mm, colour ‘Set up and Information Screen’ (SIS), which provides quick and easy access to a range of useful information.
Visibility
Boosting productivity, saving time and making the difference. Work smarter with implements and drive safely on the roads with 360° cab visibility.
Mechanical Cab Suspension
Mechanical cab suspension performs an excellent job of evening out irregularities in the terrain by means of a pair of shock absorbers.
EASY AND SECURE ACCESS
Large wide door, steps, rails and tiltable steering column provide best-in-class accessibility to the cab.
Working Lights
The addition of the 16 LED WORKING LIGHTS option transforms night into day with its outstanding brightness capacity. This package also includes day-time running LED signatures, enhancing an already very attractive design.
Radio/Phone
Access radio or your phone's functions through the Datatronic 5.
Choose the roof to suit you
A choice of cab roof allows you to tailor your MF 7S to offer better visibility with the Visio Roof or for more natural ventilation.
Design
The face of the new MF 7S captures and holds your attention. At its centre is the iconic MF triple triangle logo, around which flows the powerful shape of the MF bar lights and the new MF grey sabre.
Essential Specification
Essential is the base specification for the MF 7S Series, but it is anything but basic. It provides all the key elements you would expect from MF, with a blend of simplicity, ease of use and versatility to fit the needs that require power and performance.
Essential Panoramic cab
The Essential Panoramic cab option provides ultimate, all-round visibility for maintenance operations. The wide, one-piece polycarbonate screen is extremely tough and protects operators from flying debris.
Efficient specification
Equipped with key, productivity enhancing features, the Efficient package helps you to work faster, to a higher standard and with more accuracy.
Exclusive specification
Exclusive tractors, equipped with many advanced features, are designed for more intensive, larger-scale operations seeking cost-effective benefits for the business.
DATATRONIC 5
At the heart of the system is the intuitive Datatronic 5, touch-screen terminal, this does not only manage the tractor functions, but it allows a complete control of all ISOBUS compatible implements.
FIELDSTAR 5
The new Fieldstar 5 terminal is designed in order to create a more intuitive Precision Farming experience, providing a system that delivers a straightforward an easy to use experience, improving efficiency, productivity and profitability.
MF Guide
MF Guide is MF’s full featured, hands free steering system, available on new tractors or as an after-market installation. It is capable of delivering sub-metre, decimetre and centimetre accuracy, increasing the efficiency of your farming.
MF Section Control
With the fully automatic Section Control for ISOBUS implements, operators can apply seeds, fertilizer or Crop protection products without overlapping. This prevents double treatment and areas worked outside of the field edges.
MF Task Doc
The MF Task Doc system has a real place in the future of agriculture, helping farmers to become more productive through the knowledge brought by putting precision-measured data at the business owner’s fingertips.
MF Connect
MF Connect service enables you — and your dealer — to coordinate, optimize and seamlessly connect your fleet, to better manage maintenance and remotely monitor equipment in the field.
Dyna-VT Highlights:
- Stepless transmission eases the operator's job considerably, while boosting fuel efficiency in all conditions
- Simple, infinite speed control, from 0.03 speeds to 40 km/h or 50 km/h* available with 40 km/h super Eco or 50 km/h* Eco
- The choice of two speed ranges optimises torque for different applications
- Lever, pedal control means operator can choose his preferred mode
- 'Supervisor' maximises output under varying loads
- New Automatic mode enables operators to adjust forward speed, while automatically regulating engine speed according to load and speed
- Shuttle and Pedal agressivenes adjustment with brake pedal to neutral feature
Operator Environment - Package Specifications
|
Essential
|
Essential Panoramic |
Efficient
|
Exclusive
|
---|---|---|---|---|
Information aboutthe different packages |
Essential is the entry-level MF 7S Series, but it is still has a high standard specification. It includes all the key elements you would expect from Massey Ferguson, with a blend of simplicity, automation and ease of use to suit a wide range of applications and operations. |
Clear, unobstructed visibility to the right-hand side allows safe and efficient operation of side-mounted equipment. The wide, one-piece screen is extremely tough and protects the operator from any flying debris. A special anti-scratch coating and dedicated wash/wipe system ensures superb visibility in all weathers. For local authority and roadwork, the cab can be fitted with fixing brackets and wiring for hazard warning lights and signs. This cab option can provide a farmer or contactor with the opportunity to diversify their business into roadside maintenance contracting for local authorities. |
Efficient is the medium specification package for the MF 7S Series, developed to help you work smarter and in more comfort to boost productivity. |
Exclusive is a combination of high-spec versatility and refinement dedicated to operators looking for a tractor with advanced features and functions in terms of ergonomics, comfort, automation, Smart Farming capacities and full connectivity. |
Standard Features |
- Brake-to-neutral - Air-conditioning with manual adjustment - Telescopic, wide-angle wing mirrors - 2 USB ports - Control Centre with T-lever transmission operation - Dyna-6 Super Eco with standard Automatic Mode - Engine speed memory A - Dyna-6 Super Eco 40 km/h Eco transmission* - Closed Centre Load Sensing Hydraulics - 3 mechanical spool valves - MF Connect Telemetry-ready with 5-year subscription |
- Suspended front axle - Mechanical cab suspension - Air-conditioning with manual adjustment - Telescopic, wide-angle wing mirrors - Armrest with new Multipad - Radio/ CD / MP3 Front Aux-in / Bluetooth with microphone and controls in armrest - 2 USB ports -Automatic air-suspended seat - Dyna-6 with Automatic Mode or Dyna-VT 40 km/h Super Eco transmissions - Cruise Control and Brake-to-Neutral - Closed Centre 110 l/min hydraulics - Electrical and mechanical spool valves - Engine speed memo A or B - 2 electrical spool valves with electrical Micro-Joystick and 2 mechanical spool valves - MF Connect Telemetry-ready with 5-year subscription |
- Suspended front axle - Mechanical active cab suspension - Automatic Air Conditioning - Heated, electric-adjust mirrors - Radio/ CD / MP3 Front Aux-in / Bluetooth with microphone and controls in armrest - Automatic air suspended, swivel seat, with longitudinal shock absorber and pneumatic lumbar - All controls in the ergonomic armrest with new Multipad lever - 4 electrical spool valves with electrical micro-joystick and fingertips switches - Dyna-6 Super Eco with automatic mode or Dyna‑VT transmission - Cruise control and Brake-to-Neutral - Closed Centre 110 l/min hydraulics - Datatronic 5 touchscreen terminal 9'' (With Tractor settings management & ISOBUS integrated, camera & MF Guide compatible) - MF Connect Telemetry-ready with 5-year subscription |
|
Optional Features |
- Mechanical cab suspension - Suspended front axle - Panoramic cab with polycarbonate right-hand side window - Radio/ CD / MP3 Front Aux-in / Bluetooth with microphone - Automatic air-suspended seat - Integrated Front Linkage System and PTO - 540 & 1000, 540 Eco & 1000 Eco rear PTO - Dyna-6 Eco 50km/h transmission* - Loader ready from factory with Multifunction mechanical joystick - 4 mechanical spool valves - Fieldstar 5 terminal - ISOBUS - MF Guide system with Advanced guidelines - MF Section & Rate Control - MF TaskDoc & MF TaskDoc Pro recording all job's data exchange - MF Next Management FMIS |
- Mechanical active cab suspension - Automatic Air Conditioning - 16 LED working Lights - SpeedSteer - Heated, electric-adjust mirrors - Automatic air suspended swivel seat, with lateral suspension, with Dynamic Damping System - 50km/h* Dyna-6 Eco with supercreeper or Dyna-VT - Integrated Front Linkage System and 1,000 rpm front PTO - Loader-ready from factory with Multifunction electrical joystick - Closed Centre Load Sensing hydraulics with 150 or 190 l/min - Speedsteer - Datatronic 5 touchscreen terminal 9'' (With Tractor settings management & ISOBUS integrated, and in option, radio & phone interface, MF E-Loader, camera & MF Guide compatible) - Fieldstar 5 terminal - ISOBUS - MF Guide system with Advanced guidelines - MF Section & Rate Control - MF TaskDoc & MF TaskDoc Pro recording all job's data exchange - MF Next Management FMIS |
- Automatic air suspended swivel seat, with lateral suspension, with Dynamic Damping System - Integrated Front Linkage System and 1,000 rpm front PTO - Up to 8 electrical spool valves fully configurable and customizable on the Exclusive armrest - 16 LED working lights - SpeedSteer - Loader-ready from factory with Multifunction electrical joystick - MF Guide system with Advanced guidelines - MF Section & Rate Control - MF TaskDoc & MF TaskDoc Pro recording all job's data exchange - MF Next Management FMIS - Fieldstar 5 terminal - Radio & Phone interface, MF E-Loader management via the Datatronic 5 touchscreen terminal 9” |
* Depending on market/legislation
Tractor-Loader
When you purchase a new MF 7S tractor, whether you have ordered it as the Essential, Efficient or Exclusive specification, it can have a fully integrated loader now available from factory to deliver ultimate performance. Designed for maximum manoeuvrability and maintenance access, it forms a perfect combination being an integral part of the machine. In total control - The optional mechanical or E/H multifunction joystick has additional transmission functions such as forward/reverse and speed change for added versatility during operation.
The 3rd Live enables the operator to open/close a grab and tip or crowd an implement at the same time. You will enjoy superb visibility thanks to the new slim bonnet and exaust pipe. The optional Visioline roof improves vision of loads at height, and is particularly useful when stacking bales, for example. The ‘clutch effect’ puts the transmission into neutral when the brake pedals are depressed, allowing single-foot brake and clutch operation and making loader operation safer, easier and a lot more comfortable.
Tractor-Loader Highlights:
- Fully integrated MF FL loader now available factory-fitted to deliver ultimate performance
- Multifunction joystick option also changes direction and speed, providing total control
- Proportional control of a third spool valve enables operators to open/close a grab and tip or crowd an implement at the same time
- Highest visibility thanks to the smart profiled design of the bonnet and the dashboard
- Unrestricted manoeuvrability and access for maintenance
- Visio Roof option with Falling Object Protection (FOPS)
- Excellent manoeuvrability including tight turning angles, Speedsteer
- New Bucket Shake function on Multifunction joystick
- New quick coupling system reduces pressure losses at high flows, quicker loader movement and saves fuel
- Hydraulic implement locking can be activated via the SIS
- New, standard Engine Speed Automation on the SIS menu allows operators to increase the engine speed according to the action on the joystick
- To further improve loading performance, there is a range of output and comfort enhancing features including high flow hydraulics and the brake-to-neutral function, which also disengages drive when the brakes are applied
- New MF E-Loader available as an option to optimise the use of the loader and to measure loading tasks from the Datatronic 5 touchscreen.
Available Models
Model |
Max Power (hp) |
Max Power - EPM* (hp) |
Engine |
Transmission |
Max Torque** (Nm) |
Lift Capacity (kg) |
---|---|---|---|---|---|---|
MF 7S.155 | 155 | 175 | AGCO Power 6.6L, 6 Cylinder | Dyna-6, Dyna-VT | 750 | 9,600 |
MF 7S.165 | 165 | 185 | AGCO Power 6.6L, 6 Cylinder | Dyna-6, Dyna-VT | 800 | 9,600 |
MF 7S.180 | 180 | 210 | AGCO Power 6.6L, 6 Cylinder | Dyna-6, Dyna-VT | 860 | 9,600 |
MF 7S.190 | 190 | 220 | AGCO Power 6.6L, 6 Cylinder | Dyna-VT | 925 | 9,600 |
MF 7S.210 | 210 | 220 | AGCO Power 6.6L, 6 Cylinder | Dyna-VT | 925 | 9,600 |
* WITH EPM | ** @ 1,500 rpm with EPM |
YOUR COURTESY FLEET
- BEST-IN-CLASS CUSTOMER SUPPORT
- MAXIMUM EFFICIENCY
- TOTAL TRUST
THE ULTIMATE PROOF OF DEPENDABILITY
Available through participating MF Dealers, MF Always Running provides a temporary replacement machine to ensure owners can continue working with minimum interruption, maximising uptime while their tractors, round balers or telehandlers are being serviced or repaired.
Straightforward and dependable service
The MF Always Running courtesy fleet include tractors, balers and telehandlers, which are selected by dealers to cover the widest needs in its local area.
Following the series, the tractors can come equipped with front linkage with spool valves.
Livestock/ dairy/ mixed85hp-145hp sector |
Mixed farm140hp-180hp sector |
Arable farm150hp-210hp |
Arable/ contractor200hp-305hp sector |
Arable/ contractor320hp-425hp sector
|
---|---|---|---|---|
MF 4710 M, 100hp | MF 6S.180, 180hp | MF 7S.180, 180hp | MF 8S.265, 265hp | MF 9S.425, 425hp |
MF 5711 M, 115hp | MF RB 4160V | MF 7S.210, 210hp | MF 8S.305, 305hp | MF RB 4160V |
MF 5S.145, 145hp | MF TH.7038 | MF RB 4160V | MF RB 4160V | MF TH.7038 |
MF RB 4160V | MF TH.7038 | MF TH.7038 | ||
MF TH.7038 |
* Please contact your local Massey Ferguson Dealer to check availability in your area. Terms and conditions apply that might vary according the market or country.
