To maximise efficiency in the field and minimise downtime from crop blockages, the MF Round balers are fitted with the unique Hydroflexcontrol protection system which works in two stages:

The first stage of Hydroflexcontrol allows movement of the front part of the feed chamber floor and will automatically prevent up to 80% of potential blockages and will keep you going without unnecessary downtime.

Should a major blockage occur, stage two of hydroflexcontrol is activated by the operator, and is cleared by lowering the rear of the feed table floor hydraulically from the cab, allowing for material to easily pass through, therefore minimizing downtime.

An external control panel on the back of the baler allows control of the tailgate, wrapping ring and table and the film clamps for easy film roll change, maintenance or cleaning.

In transport mode the wrapper ring is folded forwards, reducing the overall machine length to just 5.9m for safer transport and improved manoeuvrability.

In addition to the transfer arm, the new design features two active guiding plates on both sides of the baler clearly directing the bale to the centre of the wrapper plate allowing for a faster and more secure transfer cycle.

Fitted as standard, the Rapid Reload System allows one spare roll to be carried on the baler. Roll replacement can be made in a matter of minutes, thus extending your time in the field and increasing output.

For a better efficiency, a new tying system with conveyer belt is now available on all Variable chamber Protec models to guide the net into the chamber, replacing the conventional system with movable net feed roller.

A new wash tank is now available and so useful to clean hands after replacing net or film roll, with integrated soap spender in the lid also to keep the tractor cab always clean.

For more comfort, safety and productivity, a new kit of 3 led lights is now available on Protec models, with one spot for wrapping unit and 2 spots unterneath the side panels: to work day and night at your convenience, following your needs!

The ProTec-bale-tipper is supported by a spring stamp providing suspensive relief support. It’s linked to the machine like tractors common lower link hooks & is folded into transport position by one click on your handset.

On the MF round balers, the pick-up is positioned very closely to the rotor, therefore improving crop flow and reducing the risk of blockage.

The hydraulically driven wrapper table consists of two rollers and three endless belts mounted on a welded frame for extra durability.

A sensor underneath the middle belt will allow for wrapping to begin only after the bale is fully positioned on the table, while four large side support rollers keep the bale centred while wrapping.

Twelve film roll holders are conveniently located at a comfortable height on both sides of the baler and with two additional rolls installed on the wrapper, increase uptime in the field.

Higher operating speeds are possible with the MF cam-less pick-up design. With fewer moving parts, the cam-less pick-up is quieter, simpler and more reliable. Low maintenance and less adjustments save time and increase productivity.

The wrapping ring is driven by a set of two rubber rollers, ensuring plenty of gripping surface, eliminating slippage and reducing noise levels.

Designed to withstand the heaviest bale loads, the robust frame with its quiet running gear operates at up to 35 rpm smoothly for trouble free wrapping, bale after bale.

The pick-up system has five tine bars with each one being spaced only 64mm apart, providing higher capacity and a smoother even feed at high speed.

An optional bale tipper puts bales on their ends, preventing them from rolling away and making for easier loading on the trailer. The operator can also choose between automatic and manual unloading modes.

Once the bale is transferred to the centre of the wrapper table, a hydraulically driven wrapper ring begins its rotation even before the tailgate is fully closed, completing the cycle well before the next bale is formed.

Massey Ferguson Protec range is equipped with large low-pressure tyres for reducing ground compaction. They permit greater stability and manoeuvrability on headlands without damaging turf also during very wet conditions.

To ensure gentle bale unloading, the wrapping table is lowered, thus minimising the bale’s rolling speed, preventing film damage and maintaining the ideal bale shape.

The baler features a choice of 2.25m or 2.40m pick-up with a camless design offering higher working speed, reduced maintenance and reduced noise levels.

Four durable, double-ply, seamless belts have excellent grip on the bale. With two stretch-resistant core layers made of a special synthetic material, the belts can withstand high loads when forming heavy silage bales.

A patented bale formation system features a sliding tailgate that moves downwards as the bale forms allowing the growing bale to move backwards. The bale chamber has a small bale start-off section with two additional rollers for better bale formation.

The bale chamber side panels are securely aligned during the production process with two large diameter tubes welded to the frame, providing a hardwearing and rigid connection for extended durability and better bale density control.

The tried and tested Varionet net wrapping system features a special net tensioning and spreading device that is capable of dealing with various widths and types of net allowing for fast wrapping of bales from edge to edge or over the edge.

The E-Link Pro monitor with integrated ISOBUS technology features a large bright screen which offers great visibility of multiple parameters, giving the operator more information and control of the baler.

Specific field or customer information, such as the number of bales or hours worked, can easily be set and collected with the Wizard and later exported via a USB connection for easy management of records and further performance analysis.

Utilising a single in-cab terminal in the tractor for all implements reduces cab clutter and can make for simpler and more accurate control by drivers who may carry out a wide range of operations with different machines.

Full width side doors provide easy access for maintenance. The smooth surface design prevents dust accumulation beneath the panels while secure locking prevents unintended opening and potential damage.

The Powersplit gearbox equally divides and transfers power to drive the rotor unit on one side and the roller drives on the other, reducing the overall power requirements by simplifying the drivelines.

Regular and sufficient lubrication of roller bearings is extremely important, particularly in adverse conditions. Centralized grease banks for roller bearing lubrication are located in convenient positions for easier access and reduced service time.

Automatic chain lubrication with individual adjustment for each chain guarantees sufficient oil supply, reduces maintenance time and extends chain service life. For added durability the highest quality chains are used throughout the baler.
