MF RB V

Variable Chamber Baler Wrapper Combination

Massey Ferguson RB 4160V and RB 4180V variable chamber balers share a common platform and produce bales up to 1.60m or 1.80m in diameter respectively and feature patented bale formation system with Constant Pressure System (CPS) that combines spring and hydraulic action producing dense and uniform bales.

Consistent bale density is essential for all baled products, and the new range of MF variable chamber round balers offer farmers the best solution due to their class-leading compaction, cutter and pick-up capabilities.

Current Offers & Promotions

MF Round Balers | Variable chamber

MF Round Balers | Variable chamber

Baling excellence

1+2 @ 0% (up to 50% RRP) Your MF Round Baler comes with 2 year's MF Care Warranty*

Key Benefits

High speed pick-up

High speed pick-up

Higher operating speeds are possible with the Massey Ferguson camless pick-up design. With fewer moving parts, the camless pick-up is quieter, simpler and more reliable. Low maintenance and less adjustments save time and increase productivity. The pick-up system has five tine bars with each one being spaced only 64mm apart, providing higher capacity and a smoother even feed at high speed. On the Massey Ferguson round balers, the pick-up is positioned very closely to the rotor, therefore improving crop flow and reducing the risk of blockage.

Xtracut for optimum cutting performance

Xtracut for optimum cutting performance

Designed for optimum performance, Massey Ferguson round balers can be equipped with 13, 17 or 25 knives. Cutter units are fitted with the longest knives on the market, making sure that no material will pass through uncut. Xtracut 17 and 25 feature two sets of hydraulically operated knife banks with separate control from the cab depending on customer requirements.

Hydroflexcontrol - Two stage protection system

Hydroflexcontrol - Two stage protection system

The first stage of Hydroflexcontrol allows movement of the front part of the feed chamber floor and will automatically prevent up to 80% of potential blockages and will keep you going without unnecessary downtime. Should a major blockage occur, stage two of hydroflexcontrol is activated by the operator, and is cleared by lowering the rear of the feed table floor hydraulically from the cab, allowing for material to easily pass through into the bale chamber, therefore minimizing downtime.

Bale chamber

Bale chamber

The bale chamber side panels are securely aligned during the production process with two large diameter tubes welded to the frame, providing a hardwearing and rigid connection for extended durability and better bale density control. Four durable, double-ply, seamless belts have excellent grip on the bale. With two stretch-resistant core layers made of a special synthetic material, the belts can withstand high loads when forming heavy silage bales.

Constant Pressure System

Constant Pressure System

The Massey Ferguson Constant Pressure System (CPS) retains pressure using two large springs during bale formation, thus maintaining the correct pressure from the core outwards. Once the core is formed, the hydraulic system takes over, which increases the pressure until the complete bale is formed. This keeps the bale surface pressure constant throughout the complete cycle.

Technology & Innovation

The number of unique and patented features make our balers stand out from the crowd. Massey Ferguson variable chamber balers can be operated with tractor mounted monitors using ISOBUS connection or with choice of E-Control or E-Link Pro monitoring systems, both allowing full control of the baler from the tractor seat.

Available Models

Model

Chamber diameter (m)

Chamber Width (m)

Pick-Up Width (m)

Approximate weight (kg)

MF RB 4160 V Classic 0.7 - 1.6 1.23 2 / 2.25 3,690
MF RB 4160V Xtra 0.7 - 1.6 1.23 2.25 / 2.4 3,950
MF RB 4180V Classic 0.7 - 1.8 1.23 2.25 3,870
MF RB 4180V Xtra 0.7 - 1.8 1.23 2.25 / 2.4 4,070

Customer Reviews & Testimonials

Darren Hobbs

Darren Hobbs

“I looked at the new Massey Ferguson balers and liked the design which obviously retains all the best points from the Welger models but includes practical improvements too.”

Read Full Testimonial
George Basey-Fisher

George Basey-Fisher

“Compared to other manufacturers we have always found Massey Ferguson straightforward. Products come with what you expect and there are no hidden extras, and parts and repairs are reasonably priced."

Read Full Testimonial
William Stratton

William Stratton

“Our MF 4160 V round baler bales everything from the wet silage here in Scotland to the best of hay in a good summer,” says William Stratton, agricultural contractor from the Newmachar area of Aberdeenshire.

Read Full Testimonial
