MF 5700 M
With this new and straightforward range, Massey Ferguson offers a highly modern, high performance, heavy duty tractor that delivers exceptional efficiency for every type of farmer.
Five new four-cylinder MF 5700 M Series tractors provide a choice of a superbly engineered 12 x 12 gearbox or the renowned Dyna-4 transmission. With up to 5.2t lift capacity, it is ideally suited to a wide range of field work as well as loader operations and transport.
All are equipped with a host of modern features, a high specification and available with a range of options and accessories.
Key Benefits
Technology & Innovation
Dyna-4
The impressive performance and efficient design of the Dyna-4 transmission provides unbeatable productivity, control and convenience, with completely clutchless shifting of 16 forward and 16 reverse speeds.
AutoDrive
AutoDrive (option) provides automatic shifting and operates in two modes: AutoDrive Power mode (Powershift changes at 2,100 rpm) and AutoDrive Eco mode (Powershift changes at 1,500 rpm).
Brake to Neutral
Brake to Neutral switch (Option) simultaneously operates the clutch as soon as the brake pedal is pressed. This eases the load on the operator, while increasing efficiency and convenience and is particularly useful for loader operations.
Power Control
The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shuttle between forward/reverse, shift Dynashift speeds and ranges and select neutral, leaving the right hand free.
Right-Hand T-Handle
Simply move the T-shaped transmission control lever forwards or backwards to change up or down through the four Dynashift ratios. To change range, simply press the range selection button as you move the lever.
Super Creeper Option
A Super Creeper option is also available when the slowest speeds, down to 140m/hr, are required for the job in hand.
Completely Flat Floor
A completely flat floor creates the most accessible and spacious operator environment in this sector of the market, with a pillar to pillar width of 1,300mm.
Dashboard
The advanced Dashboard displays engine and PTO speeds, service intervals, fuel consumption, distance travelled, area worked, oil temperature and tractor hours, Engine speed memory and service information.
360 Visibilty
The great view over the bonnet is maintained thanks to the compact ‘All-in-One’ SCR system, providing 360° visibility for optimum comfort and safety at work.
Mechanical Cab Suspension
Mechanical cab suspension performs an excellent job of evening out irregularities in the terrain by means of a pair of shock absorbers.
NEW ELECTRONIC JOYSTICK ON ARMREST
New electronic multifunction joystick available on MF 5700 M Dyna-4 allows operators to control the loader function as well as the transmission forward, reverse and speedshift.
100 Litres Combined Flow
At the press of a button the hydraulics can deliver 100 litres/min oil flow, making the higher flowrate available to provide extra speed and power for loader operations.
IPTO
Control is via a modern independent PTO (IPTO) clutch, which is electro-hydraulically engaged and ‘eases’ the engagement, to protect the driveline by gradually taking up the drive.
Electronic Linkage Control - ELC
The industry leading ELC is provided as standard. The system provides precise and responsive control of linkage functions ensuring accurate management of working depth for soil engaging implements plus working height for other implements.
Rear Axle
The heavy duty, structural axle casting design contains new inboard reduction units, which employ epicyclic gears for the final speed reduction.
Visio Roof
Operators really value the Visio Roof option, which provides perfect visibility when stacking bales or loading trailers. The roof is fully FOPS (Falling Object Protection) compliant.
Available Models
Model |
Max Power (hp)* |
Engine |
Transmission |
Max Torque (Nm)** |
Lift Capacity (kg) |
---|---|---|---|---|---|
MF 5709 M | 95 | AGCO Power 4 cylinders | Dyna-4 | 406 | 4,300 |
MF 5710 M | 105 | AGCO Power 4 cylinders | Dyna-4, Mechanical Synchronised 12 x 12 | 435 | 4,300 |
MF 5711 M | 115 | AGCO Power 4 cylinders | Dyna-4, Mechanical Synchronised 12 x 12 | 455 | 4,300 |
MF 5712 M | 125 | AGCO Power 4 cylinders | Mechanical Synchronised 12 x 12 | 520 | 5,200 |
MF 5713 M | 135 | AGCO Power 4 cylinders | Mechanical Synchronised 12 x 12 | 540 | 5,200 |
* @ 2,000 rpm | ** @ 1500 rpm |
YOUR COURTESY FLEET
- BEST-IN-CLASS CUSTOMER SUPPORT
- MAXIMUM EFFICIENCY
- TOTAL TRUST
THE ULTIMATE PROOF OF DEPENDABILITY
Available through participating MF Dealers, MF Always Running provides a temporary replacement machine to ensure owners can continue working with minimum interruption, maximising uptime while their tractors, round balers or telehandlers are being serviced or repaired.
Straightforward and dependable service
The MF Always Running courtesy fleet include tractors, balers and telehandlers, which are selected by dealers to cover the widest needs in its local area.
Following the series, the tractors can come equipped with front linkage with spool valves.
Livestock/ dairy/ mixed85hp-145hp sector |
Mixed farm140hp-180hp sector |
Arable farm150hp-210hp |
Arable/ contractor200hp-305hp sector |
Arable/ contractor320hp-425hp sector
|
---|---|---|---|---|
MF 4710 M, 100hp | MF 6S.180, 180hp | MF 7S.180, 180hp | MF 8S.265, 265hp | MF 9S.425, 425hp |
MF 5711 M, 115hp | MF RB 4160V | MF 7S.210, 210hp | MF 8S.305, 305hp | MF RB 4160V |
MF 5S.145, 145hp | MF TH.7038 | MF RB 4160V | MF RB 4160V | MF TH.7038 |
MF RB 4160V | MF TH.7038 | MF TH.7038 | ||
MF TH.7038 |
* Please contact your local Massey Ferguson Dealer to check availability in your area. Terms and conditions apply that might vary according the market or country.
