Reliable Performance in a Compact Design

Introducing the MF 1M

The MF 1M Series combines modern design with robust performance.

Perfect for municipalities, equine centres and the leisure industry, as well as estate management and grounds care, these machines operate with smooth efficiency in confined spaces, low buildings and areas with restricted access. They come with features that enhance convenience and ease of operation to save you time and give you the versatility you need to handle any task your day serves up.

Key Benefits

Image Gallery

Technology & Innovation

The power you need

Efficient drivelines with fuel-efficient, reliable 3-cylinder engines offering 20-40 HP. The MF 1M.25 engine produces 33% more torque at 19% lower revs than similar competitors, resulting in lower noise levels and excellent fuel efficiency.

Efficient Mechanical Transmission

The nine-speed, three-range transmission to increase working efficiency is standard on the MF 1M.20 making it easier to achieve the ideal combination of engine and travel speeds whatever the application.

Smooth Hydrostatic Transmission

The stepless hydrostatic transmission with auto accelerator and auto cruise modes is available on the MF 1M.25, MF 1M.35 and MF 1M.40, providing exceptional ease of control and making it easy to achieve the ideal speed for every task.

Pro-Quality Mowing Decks

A range of mid-mounted grass cutter decks brings additional options and features. For the MF 1M.25, customers have the choice of a 54-inch with mulching or 60-inch side-discharge.

Easy and Quick Connection

The Mower Deck Override system makes fitting and removal easy with the tractor able to simply drive onto and over the deck.

Three Tyre Options

Choose from turf, ag or industrial tyre Options to fit your needs.

Convenient Power and USB Ports

A 12-volt power supply and a handy USB connection with both A and C type sockets are standard.

Enhanced Visibility and Comfort

On the cab model, comfort and convenience are further enhanced by a wide range of standard equipment, including air conditioning, a new hydraulic joystick and LED worklights.

Operator Environment

The ROPS is available on all models, while the MF 1M.25, MF 1M.35, and MF 1M.40 offer an optional cab. Both configurations have easy-to-reach controls and an adjustable steering column to ensure a comfortable seating position.

Power for different applications

Designed to handle modern implements, the MF 1M.35 and MF 1M.40 has 1,200kg and MF 1M.25 has a 900kg rear linkage lift capacity, while the MF 1M.20 comes with a 600kg lift capacity as standard, with an upgrade to 900kg available as an option.

Optimised Hydraulic Performance

The main hydraulic pump delivers 41.5 l/min on MF 1M.35/1M.40 and 20.9 l/min on MF 1M.20/1M.25, with up to two spool valves for attachments. A separate 12.3 l/min pump powers steering, keeping the main supply available for implements.

Mid-Mounted Hydraulic Spools

All models come with a rear PTO as standard. The MF 1M.25, MF 1M.35 and MF 1M.40 has a two-speed rear PTO with selectable 540/750rpm. A mid PTO with 2,000rpm output is standard on the MF 1M.25.

Versatile PTO Options

Both models come with a PTO as standard. The MF 1M.25 has a two-speed rear PTO with selectable 540/750rpm. A mid PTO with 2,000rpm output is standard on the MF 1M.25.
