The Award Winning MF 8S Series High Horse Power Tractor, Designed by Farmers for Farmers
The exciting new MF 8S Series heralds a completely new era for Massey Ferguson. It is a tractor ahead of its time which outperforms on comfort, connectivity, ease of use, power efficiency, output, low cost of operation offering top reliability for fully maximised uptime and best return on investment.
It provides a complete farming solution designed to offer enhanced user experience encompassing the benefits of connectivity and smart farming technology.
Within months of the announcement of its launch, the MF 8S was already receiving the highest honours. The MF 8S was presented with the prestigious Tractor of the Year 2021 title, the Red Dot Award: Product Design 2021, AE50 award and Farm Machine 2022.
MF 8S | Walkaround
MF 8S | In-Action
Efficient drive-lines bring higher productivity and efficiency
New Dyna-7 powershift transmissions and Dyna-VT offering speed change in the best comfort in its class. Both transmissions come with Engine Power Management to deliver more power when it’s needed most. Perfect engine/transmission combinations provide maximum output and more power efficiency reducing power loss by up to 26%.
Low cost of operation
Engine efficiency - max power and torque at low engine revs cuts fuel consumption by 10% and reduces noise level. Unique All-In-one Stage V after Treatment for the best visibility and minimum maintenance. Easy access to daily maintenance. MFCare Repair and maintenance contract schemes.
The next level of space, comfort, ergonomy and connectivity
The quietest cab on the market with a noise level of only 68dB offering 360° visibility. Cab and front axle suspension improves driving comfort while the new MF vDisplay Digital dashboard provides all needed information at a glance. The new armrest offers best in class control of all the tractor’s operations.
Ability to work faster with the most demanding implements
Up to five* spool valves to the rear and three to the front, including front linkage, and Power Beyond installation, plus a high lift capacity hitch. The hydraulic system offers the ability to work faster with the widest implements while increasing versatility. *Up to four spool valves available with pick-up hitch.
Straightforward, smart, sustainable farming technologies
New Datatronic 5 and optional Fieldstar 5 terminal provide the latest user friendly precision farming package.
Technology & Innovation
ENGINE POWER MANAGEMENT - 20 HP BOOST
These tractors have the considerable benefit of Engine Power Management (EPM), which gives the capability of up to a 20 hp-plus power boost, plus extra torque, whenever that bit extra is needed.
MF 8S Engines
Latest Stage V AGCO Power 6-cylinder / 7.4 litre engines deliver more power, torque, and performance at low rpm reducing operating costs.
Dyna-7 offers efficient operation of a total of 28 forward and reverse speeds in four ranges and seven seamless gears. This cost-effective transmission delivers smooth and intuitive operation in manual mode or can even be operated fully automatically.
Stepless transmission brings complete operator comfort and optimum fuel efficiency at all times. New Automatic mode enables operators to adjust forward speed, while automatically regulating engine speed according to load and speed.
ALL-IN-ONE STAGE V ENGINES
These comply with the strict Stage V emission regulations using Massey Ferguson’s award-winning ‘All-in-One’ system, which now includes a straightforward ‘soot catalyst’.
The encapsulated engine contributes to ultimate engine performance improving cooling capacities by always getting fresh air. It also insulates the cab from noise, heat and vibrations.
Power Lever Control
Exclusive, Simple, the unique Massey Ferguson Power Control lever provides straightforward three-in-one operation. Leaving your right hand free to operate a loader or any implement hydraulics.
The Multipad lever operates the transmission as well as controlling cruise control, the rear linkage, PTO, headland management, spool valves through the integrated micro-joystick. All operations are easily to hand for greater comfort.
Front Axle Suspension
Improved comfort and safety for transport applications and greater traction is delivered by a new and innovative front suspension.
Reduces operator effort and provides faster turns - maximising your time in the cab. It enables the operator to adjust the steering ratio and select the number of turns of the steering wheel required for a given amount of steering angle turns.
TIGHT TURNING CIRCLE
The curved design of the chassis and bonnet ensures one of the best turning circles on the market: 5.7 m*. (*Track 1950mm with 600/70R30 front tyres)
Wheelbase length is 3.05m offering improved stability with or without a heavy implement, maintaining high levels of traction in the field and increased comfort in transport.
TM 1000 Progressive Traction
The Trelleborg Tyres provides maximum traction, soil preservation & low fuel consumption, with an excellent handling and comfort.
The striking ‘neo-retro’ design pays tribute to the brand’s heritage, illustrated by a new interpretation of the iconic MF grey sabre stripe on the side and horse head collar motif on the bonnet, which dates back to the MF 100 series.
Control Centre Armrest
The new Control Centre armrest fitted with the latest easy-to-use MultiPad lever provides complete fingertip control. This ISOBUS compatible lever operates all the tractor functions and includes an integral micro-joystick to control two spool valves.
MF 8S Exclusive Package
The Exclusive specification is a comprehensive package providing operators with exceptional comfort and ease of use as well as genuine performance enhancing features to increase productivity and efficiency.
With noise levels of just 68dB, it is one of the quietest in the market and, with an interior volume of 3.4m³, it is also one of the most spacious. The 6,6 m² of glass surface guarantees 360° visibility.
There’s also extra sockets for mobile phones, radio, USB, Bluetooth connection, DAB+ Radio, telescopic side mirrors and electric de-icing, plus automatic air conditioning.
Massey Ferguson offers the best-in class seat depending on models and options providing outstanding comfort.
16 Led Lights
The 16 LED LIGHTS OPTION transforms night into day. These include automatic beacon activation, comfort light delay at end of the day with automatic work lights extinction.
Massey Ferguson MF 8S Series tractors are built on a 3.05m wheelbase that provides stability and improves traction when working with wide, demanding implements, offering up to nearly 10% more traction power.
All models come with a four-speed PTO as standard, providing a choice of 540, 540ECO, 1,000 or 1,000ECO, which means operators can always select the right speed for power or economy.
Optional Hydraulic Systems
A 205 litre/min flow is an option, which can also be supplied as an ECO version, generating the flow at 1,650rpm (230l/min at max at rated engine speed). Up to five electronic rear spool valves can be specified.
Load-Sensing Hydraulic System
A 150 litre/min closed-centre, load-sensing hydraulic system is standard, providing 36% more flow compared with the previous system.
Three-point linkage capacity is increased by 7% to 10,000kg and, with powerful new hydraulics, these tractors handle and operate large, wider implements.
Front Linkage Option
A new 4,800kg capacity front linkage option, fully integrated into the tractor, comes with the option of an ISOBUS socket.
MF Section Control
With the fully automatic Section Control for ISOBUS implements, operators can apply seeds, fertilizer or Crop protection products without overlapping. This prevents double treatment and areas worked outside of the field edges.
MF Task Doc
The MF Task Doc system has a real place in the future of agriculture, helping farmers to become more productive through the knowledge brought by putting precision-measured data at the business owner’s fingertips.
MF Guide is MF’s full featured, hands free steering system, available on new tractors or as an after-market installation. It is capable of delivering sub-metre, decimetre and centimetre accuracy, increasing the efficiency of your farming.
The Datatronic 5, touch-screen terminal, does not only manage the tractor functions, but it allows a complete control of all ISOBUS compatible implements. It also give access to the radio functions, permit to receive and make calls, and other functions.
An optional Fieldstar 5 terminal can be used to manage all of the relevant MF Technologies. It now also records the field boundaries and provides automatic field detection.
The MF vDisplay digital dashboard shows all the tractor information at a glance. Easy to read and with intuitive operation, its clear display can be personalised and changed by simply scrolling through settings with a rotary knob by the steering wheel.
A new antenna rail, positioned at the front of the cab, enables easy mounting of a choice of GPS receivers up to RTK precision. For security and risk avoidance, the antenna is locked in place with a key as standard.
MF Connect service enables you — and your dealer — to coordinate, optimize and seamlessly connect your fleet, to better manage maintenance and remotely monitor equipment in the field.
Operator Environment - Package Specifications
|Exclusive is a combination of high-spec versatility and refinement dedicated to operators looking for a tractor with advanced features and functions in terms of ergonomics, comfort, automation, Smart Farming capacities and full connectivity.|
- QuadLink front axle suspension
- Mechanical active cab suspension
- Automatic Air Conditioning
- 16 LED working Lights
- Rear Camera
- Mirrors with electric de-icing and adjustment
- Semi leather automatic air suspended swivel seat, ventilated, 2 levels of heating, lateral damping and dual motion backrest, with Dynamic Damping System
- DAB Radio, Bluetooth, with integrated microphone
40 km/h Dyna-VT or 40km/hr Eco, Dyna-7
- All controls in the ergonomic armrest with Multipad lever
- Closed Centre 150 l/min hydraulics
- 4 electrical spool valves with electrical joystick and fingertips
- Datatronic 5 touchscreen terminal 9'' (With Tractor settings management & ISOBUS integrated, camera & MF Guide compatible)
- MF Guide guidance ready from factory
- MF Connect telemetry with 5 years subscription
- MF Task Doc recording all jobs’ data
- 50Km/h Eco Dyna-7 or Dyna-VT 50km/hr Eco*
- Closed Centre 205 l/min or 205l/min ECO hydraulics
- 4,800 kg Cat 3 front linkage
- 1,000 rpm front PTO
- Up to 8 electrical spool valves fully configurable and customizable on the Exclusive armrest
- MF Guide system with Advanced guidelines
- MF Section & Rate Control
- MF Task Doc Pro
- MF Next Management FMIS
- Fieldstar 5 terminal
- Radio & Phone interface, MF E-Loader management via the Datatronic 5 touchscreen terminal 9”
* Depending on market / legislation
Max Power (hp)*
Max Power-EPM (hp)
Max Torque (Nm)**
Lift Capacity (kg)
|MF 8S.205||205||225||AGCO Power 6 cylinder, 7.4 Litre, All-in-One Stage V||Dyna-7, Dyna-VT||950||10,000|
|MF 8S.225||225||245||AGCO Power 6 cylinder, 7.4 Litre, All-in-One Stage V||Dyna-7, Dyna-VT||1,000||10,000|
|MF 8S.245||245||265||AGCO Power 6 cylinder, 7.4 Litre, All-in-One Stage V||Dyna-7, Dyna-VT||1,100||10,000|
|MF 8S.265||265||285||AGCO Power 6 cylinder, 7.4 Litre, All-in-One Stage V||Dyna-7, Dyna-VT||1,200||10,000|
|MF 8S.285||285||305||AGCO Power 6 cylinder, 7.4 Litre, All-in-One Stage V||Dyna-VT||1,260||10,000|
|MF 8S.305||305||NA||AGCO Power 6 cylinder, 7.4 Litre, All-in-One Stage V||Dyna-VT||1,280||10,000|
|* @ 1,550rpm (MF 8S.205 @ 1,500rpm).|
