MF 6700R Series
The MF 6700R brings more features and technology for better performance, efficiency and comfort.
The MF 6700R series is perfect for operations that need a highly productive and economical machine. With power ranging from 112hp (82kW) to 132hp (98kW), its high operating efficiency is due to its autonomy, AGCO Power Engine, the Dyna-4 transmission, and advanced hydraulic system.
This new series of tractors offers a unique and straightforward concept aimed at increasing your productivity and performance in your daily operations. In addition to its spacious and ergonomically designed cabin, the MF 6700R series has the optional AutoGuide ready system, which is a fully integrated satellite assisted-steering-ready solution.
The MF 6700R provides you with an ideal solution in reliability, technology, and productivity without compromise.
4 Cylinder Tier 2 AGCO Power engine
The MF 6700R series is designed to provide unmatched power and performance and is configured to meet Tier 2 emissions standards and are specifically designed to suit the requirements of agricultural applications where high levels of power and torque are essential and their rugged construction provides enhanced reliability. At a low rated engine speed of only 2200 revs/min, you are assured of enhanced fuel efficiency whilst also minimizing noise and wear. The long piston stroke design provides high levels of torque across a broad speed range with maximum torque being achieved at only 1200 revs/min.
With a maximum speed of 40 km/h, the Dyna-4 transmission is equipped with four powershift ratios in each of four mechanical ranges providing 16 Forward and 16 Reverse speeds, all operated without the need to use the clutch pedal. Speedmatching selects the most appropriate powershift ratio automatically during range changes ensuring smooth and progressive speed changes. The brake to neutral feature of the Dyna-4 transmission specified for MF 6700R Series tractors allows the transmission to be temporarily placed in neutral when the brake pedal is pressed and re-engaged when the brake pedal is released. This is particularly useful for applications where frequent stops are required, such as when using a round baler or feeder mixer.
Closed Circuit Load sensing hydraulics (CCLS)
The Closed Center Load Sensing (CCLS) Hydraulic System gives you more performance with up to 200 Bar pressure or 110 liters/min oil flow. The MF 6700R Series comes equipped with 2 auxiliary hydraulic valves as standard, with a third valve available as a factory option. All valves are double acting with Float, Kick out, Zero Leak and load sensing allowing you both single and double acting functions. Each auxiliary valve is equipped with a flow divider that controls the oil flow to the implement.
Provides oil flow directly from the pump through a load sensing spool valve block, which allows you to use remotely operated spool valves, that are found on mordern loaders, potato harvesters and planters.
Electronic linkage control (ELC)
MF 6700R Series tractors benefit from the latest generation of electronic lift controllers ensuring accurate productivity is always achieved. The operator can set the maximum allowable lift height of the linkage to protect PTO shafts and universal joints and to reduce cycle time at headland turns.
Accurate draft control
Massey Ferguson’s digital ELC system gives the highest standards of draft control with more accurate depth settings and consistent working depth. The result is more weight transfer, less wheel slip, reduced tyre wear and reduced fuel consumption whilst still maintaining great in field performance.
Active transport control (ATC)
ATC dampens the forces acting on the tractor when transporting or operating linkage mounted equipment at speed, achieving greater productivity, safety and comfort.
This configuration equips the tractor with the various components, including the electro-hydraulic steering valve, wheel angle sensors, harnesses, etc. to allow the installation of an aftermarket guidance system. This AutoGuide ready configuration allows you to install the most appropriate guidance system to achieve the level of accuracy and technology required whilst ensuring good correction signal reliability and aftermarket support that is available in the market where the tractor will operate.
To futher increase your productivity, MF 6700R series is equipped with an automatic start & stop PTO that is controlled by simply operating your linkage controls.
Built for hard work and long days
To maximize traction in field applications an electro-hydraulic differential lock is specified for the front and rear axle. This is activated on the move or stationary via a soft touch button giving you true 4WD. Hydrostatic power steering with a maximum 55° steering angle provides excellent maneuverability amongst buildings and on field headlands. The axle oscillates 11º maintaining traction, stability and steering control in difficult ground conditions.
Incomparable comfort and productivity
The MF 6700R cab is easily accessible from both sides of the cab. Excellent workmanship and comfort is seamlessly integrated in it. Standard specification includes air conditioning, tilting and telescopic steering column swivelling seat with mechanical suspension and digital instrument panel with performance monitor.
Simple daily maintenance
The bonnet lifts up to provide direct access to the engine air filters, diesel cooler, air conditioning condenser, hydraulic and water radiators, as well as the intercooler. The engine oil filters and oil dipstick are easily accessible on the side of the engine.
Max Power hp (kW)*
Max Torque (Nm)**
Lift Capacity (kg)
|MF 6711R||112 (83)||4 Cylinder, AGCO Power L CTA Tier 2||Dyna-4||460||5200|
|MF 6712R||122 (91)||4 Cylinder, AGCO Power L CTA Tier 2||Dyna-4||510||5200|
|MF 6713R||132 (98)||4 Cylinder, AGCO Power L CTA Tier 2||Dyna-4||540||5200|
|* @2200 rpm | ** @1200 rpm|
