MF FL

Products

Hard working, high performance loaders

Introducing the MF FL

The new generation of Massey Ferguson front loaders

If you need a robust, reliable loader to complement your Massey Ferguson tractor then you don’t need to look far. MF tractors with MF FL loaders are the ultimate combination of rugged ability, hard work and reliability.

Full integration of tractor and loader is achieved easily with the MF FL Series, to suit 75 - 405 hp Massey Ferguson tractors. You can choose from either ‘linear’ or ‘parallel’ linkage, available throughout an extensive range, along with numerous options and accessories to enhance performance and productivity.

Key Benefits

Image Gallery

Technology & Innovation

From the strength and security of the subframe to the slim yet robust design of the welded box section beams, MF FL Series loaders deliver industry-leading features that ensure maximum output and dependability from your Massey Ferguson tractor.

Strengthened Subframes

Subframes are available to fit most tractors in the Massey Ferguson range and now have larger loadbearing surfaces to strengthen their already robust construction and meet the demands of today’s high-performance tractors.

Delta Conception

Loader beam design combines strength and excellent forward visibility, with the highest quality ‘twin C-section’ steel construction neatly concealing and protecting all hydraulic hoses.

Protected and Concealed Hydraulic Hoses

Loader beam design combines strength and excellent forward visibility neatly concealing and protecting all hydraulic hoses.

Consistency in Construction

Robotised welding ensures consistency in construction throughout, whilst steel undergoes full preparation and priming before a tough and durable powder paint finish is applied.

High on productivity... low on down-time. Serviceability, low maintenance and ease-of-use of both tractor and loader has been a key consideration in the design and construction of the MF FL series, making things simple, easy, quick and highly efficient.

Selecto-Fix

Many attachments in the range can be equipped with ‘Selecto-Fix’. This provides a rapid, easy and positive hydraulic connection, The flat face couplings are very easy to clean and there is no no risk of spillage or leakage.

Clic-On

When an implement is detached, the ‘Clic-on’ device holds the locking pins in their retracted position. Attaching an implement and rolling back the tool carrier allows the locking pins to return to their locked position, automatically.

Lock and Go System

All loaders are designed with the standard ‘Lock & Go’ system. Requiring no tools and incorporating rigid support legs, the ‘Lock & Go’ system is simply designed to save time, enabling straightforward attachment/detachment.

Fast Hydraulic Coupling

Fast hydraulic coupling of tractor and loader is made easy by compact design connections. For faster hydraulic connection, the ‘Hydroquick’ or QC4 and QC6 multicouplers are available as an option.

Precise Self-Levelling

Precise and automatic control of your implement position. Once the implement angle is set it stays in its position. The self levelling loaders will also benefit from an increased crowd angle (minimum 57°) at lower height.

Easy Servicing

Outward-facing grease points easily accessible and covered.

Hydraulic Implement Locking

Hydraulic implement locking is also available as an option. It offers higher comfort when attaching and detaching an implement by allowing the operator to stay in the cabin.

MF FL Series loaders set the standard in control and ergonomics, ensuring simple and effective operation, leading to higher levels of comfort, safety and output. You’ll never have a more efficient tractor/loader combination.

Power Control

The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shuttle between forward/reverse, shift Dynashift speeds and ranges and select neutral, leaving the right hand free.

Optional 3rd Live

Convenient option to the loader hydraulic control is 3rd Live which enables the operator to open/close a grab and tip or crowd an implement at the same time.

Optional SoftDrive Suspension

Stresses on loader and tractor, as well as the operator, can be reduced by the optional addition of the innovative ‘SoftDrive’ shock absorption system.

LED Worklights

An optional set of LED worklights is available to give you maximum visibility at night. They’re perfectly integrated in to the beam and will provide maximum productivity and vision for longer working days.

MF E-Loader

Easily operated through the Datatronic 5 touchscreen, MF E-Loader enables operators to monitor the loader functions, weigh individual loads, automate the grapple operation as well as set-up and save the lift limits.

Available Models

Model	Type	Maximum Lift height* _(m)	Max lift capacity at full height** _(kg)
MF FL.4018	Parallel	4.02	1,780
MF FL.4121	Parallel	4.06	2,090
MF FL.4323	Parallel	4.25	2,310
MF FL.4624	Parallel	4.6	2,420
MF FL.5033	Parallel	4.96	3,270
MF FL.3723	Non-Parallel	3.79	2,310
MF FL.4125	Non-Parallel	4.06	2,470
MF FL.4227	Non-Parallel	4.25	2,730
* Measured at Pivot Pin \| ** To 1.5m height - at Pivot Pin

Implements

This comprehensive range of bale handling implements has been thoughtfully designed to provide safe, efficient and reliable operation through the complete spectrum of bale handling and distribution tasks, from field to yard.

Round Bale Spike

Quadrogrip

Silosplit

Flexibal

Flexigrip

Unigrip

Square Bale Fork

Square Bale Fork - Safety

The range consists of 5 series, to suit varying workloads, with all buckets characterised by a conical ‘hopper-shaped’ design and laser-cut ends for non-spill, non-drop ability. Also included are special Grading and High-Tipping buckets.

Series H

Series H - Variation 2

Series HD

Series HV

Series L and LV

Precision Buckets

Grading Bucket

High Tipping Bucket

From the Multibenne, a perfect all-round silage handling implement, to the versatile Silograb, this range includes some of the most reliable and innovative silage handling equipment on the market today.

Powergrab

Maxi Grapple

Silograb

Multibenne

Silocut SE

Manure Forks

Pallet forks can be specified with different dimensions and capacities The upper profile is manufactured in one piece and is able to be adjusted laterally to suit the load. This provides a very stable fork with immense strength.
