Setting New Standards. Extending Expectations.

With this new and straightforward range of tractors, Massey Ferguson has taken the concept of the sub-130hp tractor and re-engineered it from the ground up to meet the needs of present and future farming.

In this power bracket, no other range on the market today offers such an array of build specifications, options and accessories, all designed to help tailor your machine exactly the way you need it for your farming operation.

Key Benefits

Technology & Innovation

The muscle to tackle any task.
Comfort Control

Comfort Control

Smooth or quick shuttling – you choose by simply adjusting the Comfort Control to suit the job – slow and smooth or fast and efficient.

Super Creeper Option

Super Creeper Option

A Super Creeper option is also available when the slowest speeds, down to 140m/hr, are required for the job in hand.

Driveline

Driveline

Every component of the chassis has been designed from a blank sheet of paper to boast immense strength, a major factor in an agricultural tractor’s overall performance. This modern design provides versatility, power, durability and outstanding capability.

All-New Synchromesh Transmission - AME Models

All-New Synchromesh Transmission - AME Models

An all-new 12 forward x 12 reverse synchromesh transmission with the option of either mechanical or full power shuttle and 30km/hr maximum transport speed. Featuring slick gear changes and eight gears in the typical field working range from 4-12km/hr.

Power Control

Power Control

The Power Control lever provides convenient three-in-one, straightforward operation. Operators can shift between forward/reverse ranges as well as select neutral, leaving the right hand free.

A tractor that has been designed with simplicity of operation at its heart doesn’t have to have a basic operator environment. Designed from the outset with an emphasis on comfort and ease of use, the MF 5700 Series tractors make hard work a pleasure.
Neatly Positioned Gear Levers

Neatly Positioned Gear Levers

The right speed for each job is easily selected using gear levers that are within easy reach, yet positioned neatly to hand of the driver, ensuring an unimpeded passage when mounting/dismounting.

Grab Rails

Grab Rails

Grab rails mounted outside the operator station provide easy access to the footsteps, mounted directly to the machine.

The key to reliable, heavy-duty machinery is to choose a tractor that meets the requirements of today’s modern implements and utilizes them to their full potential within a wide range of agricultural applications. There is no limit to the range of powered equipment that can be put to work behind the MF 5700 Series tractors.
4WD Front Axle

4WD Front Axle

Specified with a limited slip differential, the front axle boosts traction and stability with maximum simplicity and minimal maintenance.

55 Degree Steering Angle

55 Degree Steering Angle

Manoeuvrability is maximised by the front axles 55° steering angle.

Combined Flow System

Combined Flow System

For those requiring extra flow – to boost loader performance – the MF 5700 series can be specified with a 98 litre/min combined flow system.

Open-Centre Hydraulic System

Open-Centre Hydraulic System

A simple open-centre hydraulic system, powered by two gear pumps, the 32 litres/min pump provides all the internal services, whist the 58 litres/min pump allows the electronically-controlled rear linkage to lift 4,300kg.

Spool Valves

Spool Valves

Two spool valves are fitted as standard on the platform model and an option of up to three spool valves on the cab models. Modern complex equipment can be operated with ease.

98 LITERS COMBINED FLOW

98 LITERS COMBINED FLOW

At the press of a button the hydraulics can deliver 98 liters/min oil flow, making the higher flowrate available to provide extra speed and power for loader operations.

IPTO

IPTO

Control is via a modern independent PTO (IPTO) clutch, which is electro-hydraulically engaged and ‘eases’ the engagement, to protect the driveline by gradually taking up the drive.

Electronic Linkage Control - ELC

Electronic Linkage Control - ELC

The industry leading ELC is provided as standard. The system provides precise and responsive control of linkage functions ensuring accurate management of working depth for soil engaging implements plus working height for other implements.

Available Models

Model

Max Power (hp)

Engine

Transmission

Max Torque (Nm)

Lift Capacity (kg)

MF 5710 T4* 100 AGCO Power 4.4L, 4 Cylinder, Tier 4 Mechanical Synchronised 12 x 12 410 4,300
MF 5711 T4* 110 AGCO Power 4.4L, 4 Cylinder, Tier 4 Mechanical Synchronised 12 x 12 417 4,300
* Only available in Japan & Korea
