MF 8700 S
The New MF 8700 S Series is aimed at customers looking for a New touch of high horse power and a precision farming tractor with inspired design and optimised efficiency.
The New MF 8700 S with its powerful new styling is designed to captivate you from the start. The NEW MF light bar and iconic MF triple triangle logo is at the heart of the ‘S’ effect distinctive styling, the full embodiment of MF’s power, design and engineering quality.
More power efficiency brings more traction
Up to 370hp - The most powerful tractors ever built by Massey Ferguson, delivering the ultimate output with low running costs
Efficient driveline boosts productivity
Dyna-VT transmission with Engine Power Management delivers more power when it is needed most. Perfect engine and transmission combination - matched to deliver maximum output.
Choose the correct tyre to protect your precious soil
2.15m rear wheel diameter enhances traction, reduces soil compaction and maximises performance. Michelin AxioBib 2 tyre option puts more lugs in contact with the soil, creating ‘mini tracks’ that lengthen the footprint by 26%, distribute the weight more effectively and improve traction by up to 28%.
MF Technology at your fingertips
MF Datatronic 5 touchscreen terminal: Advanced and intuitive. MF Guide: Submetre to centimetre precision from a wide choice of correction signals including Trimble and Novatel receivers. MF ISOBUS with Multipad: Efficient and comfortable to use.
Ultimate comfort and safety for a more productive working day
Large, quiet, four-post cab offers 360° visibility.
Technology & Innovation
8.4 Litre AGCO POWER 6 Cylinder Engine
These engines generate power from 270 to 370 hp.
Dyna-VT offers stepless travel from 0.03 to 40 or 50 km/h at any engine speed, operated via two speed ranges.
Fitted with an engine speed ‘Supervisor’ which automatically reduces forward speed to maintain full engine power by maintaining engine speed, whatever the job in hand.
Multipad Joystick - MF 8700 S Exclusive Models
The Command Control armrest, and the Multipad joystick, are part of the package that makes these tractors, despite their power, so easy to control with precision. A multitude of functions can be controlled in the palm of your hand.
Minimum Weight of 10.8 T
With a minimum weight of just 10.8t, the MF 8700 S Series tractors are up to 4t lighter than others in this class. This allows them to tread lightly for top work and transport.
With the continuously-variable Dyna-VT transmission, Massey Ferguson engineers have developed a power transfer system that sets a new benchmark for ease-of-use and productivity.
Dynamic Tractor Management
For control and comfort Dynamic Tractor Management (DTM) works with Dyna-VT and automatically controls engine and transmission when activated. DTM handles engine speed to maintain forward speed and minimise engine revs without losing power.
Engine Power Management - 30 HP Boost
These tractors have the considerable benefit of Engine Power Management (EPM), which gives the capability of up to a 30hp-plus power boost, plus extra torque, whenever that bit extra is needed.
Efficient Package as Standard
Efficient is the entry specification package for the MF 8700 S Series but you will notice that it is anything but basic. It provides all the key elements, with all key functions ergonomically grouped in the Control Command Centre armrest.
New Dashboard with SIS
The slim dashboard design provides for quick, clear and easy analysis of operating data, presented on a 70mm x 52mm colour screen. SIS – the Setup and Information Screen.
Best-in-class features in the ‘Panorama’ cab offer the highest levels of comfort, quietness, visibility, space, access and technology. This spacious, four-post cab ensures operators work in superb comfort with exceptional visibility and control.
This level, with its more advanced features, aims to cater for more intensive, larger-scale operations seeking cost-effective benefits for the business.
Air-Suspended Operator seat
The level of cab suspension damping can be set in from the cab, to meet the driver’s preference. Paired with a premium-class air-suspended operator’s seat, the result is one of the most comfortable rides around.
Quadlink Suspension System
The Quadlink system, which can be switched on and off, uses hydraulic accumulators acting on the front axle to dampen ride over rough roads and fields, and improve comfort and safety on transport applications.
Rear Linkage Capacity - 12000kg
With a rear linkage lift capacity of 12,000 kg, there are few tractors in this power bracket that can match the MF 8700 S series for the ability to hoist heavy implements.
Reassuring, fade-free braking comes courtesy of oil-immersed, power-assisted disc brakes, while air brakes for trailed equipment are an option.
PTO Speed Control
With the benefit of a constant power band of up to 600 rpm and the ability, with Dyna-VT, to precisely select any ground speed at the chosen engine speed, you can always achieve a perfect match of PTO speed for optimum economy.
PTO Speed Options
MF 8700 S tractors can be specified with a fully-independent 540 Eco/1000 rpm PTO, or 1000/1000 Eco speeds. External engagement and emergency stop buttons provide convenience and safety.
This new, optional feature enables the operator to adjust the steering ratio and select the optimum number of turns of the steering wheel required for a given amount of steering angle turns.
The rear hitch with a choice of pintle pin, pick-up hitch, clevis, K80 ball or drawbar has been completely redesigned to make coupling quicker, easier and safer.
MF 8700 S Tyre Options
The latest tyre equipment allows MF 8700 S models to work at very low tyre pressures, even for high traction jobs, including dual wheels with rear tyre choice up to 900mm and 2.15m diameter for better power transfer to the ground.
Fingertip Spool Valve Management System
The Fingertip Spool Valve Management System enables complex equipment to be controlled with ease and precision, and the flows to be managed precisely.
ELECTRONIC LINKAGE CONTROL - ELC
The industry leading ELC is provided as standard. The system provides precise and responsive control of linkage functions ensuring accurate management of working depth for soil engaging implements plus working height for other implements.
Up to Eight Electrohydraulic Spool Valves
Standard specification comprises four electrohydraulic spool valves, with up to eight available if required.
Fully Integrated 5000kg Front Linkage
At the front, buyers can specify a fully-integrated 5,000 kg front linkage designed to match the Massey Ferguson front suspension, with two doubleacting spool valves and a free return line.
Available from factory or via AGCO Parts with additional front, rear and tyre weights to exactly match your needs.
MF Section Control
With the fully automatic Section Control for ISOBUS implements, operators can apply seeds, fertilizer or Crop protection products without overlapping. This prevents double treatment and areas worked outside of the field edges.
Available as an option on Efficient and Exclusive models, Datatronic 5 gathers and stores data on both tractor and precision farming setting. In addition, the terminal can be used to control MF Auto Guide, ISOBUS and cameras.
The new optional Fieldstar 5 terminal is straightforward to use and is designed to create a more intuitive Precision Farming experience for the operator.
MF Task Doc
TaskDoc records data quickly and easily to create field records, make job reports and keep accurate records of inputs. This information can be transferred simply, wirelessly from the terminal in a format compatible with most farm management software.
Massey Ferguson’s complete guidance system for hands-free steering, available factory fit on new tractors or as an after-market installation. The system uses Trimble - RangePoint, Trimble - CenterPoint and RTK corrected signals to increase efficiency.
The MF Connect service enables you and your dealer to coordinate, optimize and seamlessly connect your fleet to manage maintenance and remotely monitor equipment in the field.
Max Power (hp)*
Max Torque (Nm)**
Lift Capacity (kg)
|MF 8727 S||270||AGCO Power 6 cylinder, 8.4 Litre, Tier 2||Dyna-VT||1,200||12,000|
|MF 8730 S||295||AGCO Power 6 cylinder, 8.4 Litre, Tier 2||Dyna-VT||1,300||12,000|
|MF 8732 S||320||AGCO Power 6 cylinder, 8.4 Litre, Tier 2||Dyna-VT||1,400||12,000|
|MF 8735 S||350||AGCO Power 6 cylinder, 8.4 Litre, Tier 2||Dyna-VT||1,540||12,000|
|MF 8737 S||370||AGCO Power 6 cylinder, 8.4 Litre, Tier 2||Dyna-VT||1,600||12,000|
|* @1900 rpm | ** @1500 rpm|
