MF BETA

The MF Beta combine harvesters offer a straightforward, practical design with a mix of technology and functional features that are simple to work with in the field, where time is of the essence.

A good cab environment is the key to getting the best performance from the machine and operator. Excellent visibility with ergonomically placed controls makes the workload easier and more productive.

Key Benefits

Technology & Innovation

Head first feed - start well, finish well - your header is critical to how well your combine performs - with a lifetime of experience, Massey Ferguson offers you a choice of its premium PowerFlow™ table or high capacity FreeFlow™ tables. Both have features for productivity like Automatic Reel speed and advanced table height control.
Freeflow

Freeflow

With cutting widths from 4.2 m – 6.0 m, the Freeflow™ table features a welded frame to which bolt-on panels (such as the table bottom plates) are mounted, making it extremely easy to replace parts when necessary.

PowerFlow

PowerFlow

PowerFlow™ is the industry benchmark table for high capacity in all conditions. The proven belt drive powers the crop into the combine ensuring seamless feeding.

Power Feed Roller

Power Feed Roller

The Power Feed Roller at the front of the main crop elevator gives a consistent crop flow from the table into the main crop elevator.

Full Width Auger Fingers

Full Width Auger Fingers

Full width auger fingers on the Freeflow™ table increase auger throughout, ensuring positive and fast feed into the main crop elevator.

PowerFlow Knife

PowerFlow Knife

The knife is a massive 1.14 m from the table auger, so vision and performance are optimum. The rugged PowerFlow™ belts power the crop away from the knife and into the main crop elevator at a consistent speed.

Schumacher Knife - FreeFlow Table

Schumacher Knife - FreeFlow Table

The Schumacher knife is the best performing knife in the business at 1,254 cuts a minute. Self-cleaning and consistently sharp, this keeps the crop moving in tough conditions.

TerraControl II

TerraControl II

TerraControl II provides a mix of automatic functions for the standard table-levelling (FreeFlow™ or PowerFlow™), ground-following system (Field pressure) and headland management – all the metrics are controlled from the operator’s multifunction lever.

The flexible core of the combine. MF BETA can handle crops easily for highest quality grain sample and straw quality.
Multicrop Separator - MCS

Multicrop Separator - MCS

The MCS provides a massive separation area to remove as much grain as possible before it reaches the walkers. The MCS has the ability to rotate the concave over the top of the rotary separator when it is not required.

9000 Litre Grain Tank

9000 Litre Grain Tank

The grain tanks have a high capacity (9000 litres) while the unloading rate of 105 l/sec is one of the highest in the class.

6 Row Straw Chopper

6 Row Straw Chopper

The 6 row straw chopper is specifically designed to give chopping and spreading performance suitable for farmers using reduced tillage operations. The knives are serrated to give a clean fine chop and reduce the power required.

Optional Sectional Concave

Optional Sectional Concave

MF can offer an optional Sectional concave which is designed to harvest a multitude of crops. The conversion time when moving from small grain to large seeded crops such as Soya, Maize and Sunflower can be completed in minutes rather than hours.

Straw Walker

Straw Walker

The long straw walkers feature four steps with ‘active walls’. The 21 cm high, vertical sections of the walker steps are made up of permeable grids. The front steps of the straw walkers are reinforced for maize.

Threshing Drum

Threshing Drum

The threshing drum has added weight in the form of ballast bars to increase the inertia behind the rasp bars as they thresh the heads. This reduces load on the drives, power requirement and fuel consumption.

Concave

Concave

The concave has differentiated wire spacing, and the rear section of the concave has half as many wires as the front section. This principle provides the optimum balance between high threshing capacity and good grain flow through the concave.

Shaker Shoe

Shaker Shoe

The sieve profile is the key to shaker shoe performance. The high performance sieves are specially designed with vertical tags which improve the sample and allow you to open the sieves wider for greater throughput.

Flexibility is the key - Designed to offer choice for farmers, the Massey Ferguson BETA combine range has features for performance and practicality to adapt to all variety of crops and harvesting conditions.
Rice Cylinder - Concave Version

Rice Cylinder - Concave Version

A special Rice cylinder / concave version can be ordered with unique peg and tooth design, specifically for separation in tough conditions.

ATRAK

ATRAK

Our rubber tracks option has positive transmission, auto tensioning and much lower compaction in difficult conditions. The integrated final drives are specially developed for high loads.

A good cab environment is the key to getting the best performance from the machine and operator. Excellent visibility with ergonomically placed controls makes the workload easier and more productive. Intuitive menus on the TechTouch terminal provide information at a moments notice and active warning systems protect your investment.
TechTouch Terminal

TechTouch Terminal

Perfectly in view and reach is the TechTouch terminal, providing all the relevant performance information and settings for the combine, touch screen controls with clear definition are easy to use and adjust.

Night Working Package

Night Working Package

Night working package includes H9 high intensity lights for all-round excellent visibility late into the evening.

Membrane Keypad

Membrane Keypad

The membrane keypad is located directly on the right side of the armrest and is used to operate the principle combine functions. The soft, raised keys lead directly to the individual menus on the TechTouch terminal.

Auto-Guide xls Option

Auto-Guide xls Option

Using the latest technology the Auto-Guide xls option can steer you through to higher performance optimising the field layout - easily set from the terminal Auto-Guide xls can offer accuracy down to 5cm or you can use an RTK signal if required.

PowerGrip Lever

PowerGrip Lever

The new control interface for the operator falls naturally to hand - the PowerGrip Multifunction lever sits on top of the armrest which houses all the switches for the commonly used controls.

PowerGrip Armrest

PowerGrip Armrest

The right-hand armrest is the central operating unit where the key engagement switches sit with the throttle control. Designed with a large soft pad to cushion the arm during a long day allows for maximum comfort.

AGCO Power Engine. The powerful heart.
AGCO POWER ENGINE

AGCO POWER ENGINE

We can promise you that your AGCO Power engine has been designed to match the latest emission regulations using SCR technology meaning that actually it has one of the most advanced designs on the market.

AGCO POWER ENGINE PERFORMANCE

AGCO POWER ENGINE PERFORMANCE

Fuelling is designed to give a flat torque curve, required to give a constant delivery under load despite the conditions. This coupled with the low friction drives will give you incredibly low fuel consumption per tonne and excellent fuel economy.

Good design makes for easy work - Getting the best from well-designed features on a day-to-day basis.
Easy Refueling

Easy Refueling

Easy refueling - both tanks are located next to each other for easy access.

Easy Inspection

Easy Inspection

Ladder rail makes inspection easy and safe.

One-Piece Panels

One-Piece Panels

One piece panels with lights allow for quick inspection access with lights for night work.

Radiator Cleaning

Radiator Cleaning

Safe and simple access for radiator cleaning.

Available Models

Model

Max Power (hp)*

Grain Capacity (l)

Unloading speed (l/s)

Max cutting width (m)

Engine

MF Beta 7370 360 9,000 105 7.6 AGCO Power 6 cylinder, 8.4 Litre
* with Power Boost
