If you need a robust, reliable loader to complement your Massey Ferguson® high-horsepower tractor, you don’t need to look any further. Massey Ferguson tractors with FL Series loaders are the ultimate combination of rugged ability, hard work and reliability.
The optional mechanical or electric multifunction joystick has additional transmission functions such as forward/reverse and speed change for added versatility during operation. A clever addition to the loader hydraulic control is live third function, which enables the operator to open/close a grab and tip or crowd an implement at the same time.
An unimpeded view over sloping hood is further enhanced by angling the crosstube 15° towards the tractor and positioning it lower down the curved arms, which increases visibility by 30% (when the loader is 18 inches above the ground). All the hoses and wires are also tucked away inside the loader or routed to ensure they do obstruct the view from the cab.
LOCK AND GO SYSTEM
All loaders are designed with the standard ‘Lock & Go’ system. Requiring no tools and incorporating rigid support legs, the ‘Lock & Go’ system is simply designed to save time, enabling straightforward attachment and detachment.
When an implement is detached, the ‘Clic-on’ device holds the locking pins in their retracted position. Attaching an implement and rolling back the tool carrier allows the locking pins to return to their locked position, automatically.
Precise and automatic control of your implement position. Once the implement angle is set it stays in its position. The self levelling loaders will also benefit from an increased crowd angle (minimum 57°) at lower height.
PROTECTED AND CONCEALED HYDRAULIC HOSES
Loader beam design combines strength and excellent forward visibility neatly concealing and protecting all hydraulic hoses.
Many attachments in the range can be equipped with ‘Selecto-Fix’. This provides a rapid, easy and positive hydraulic connection, The flat face couplings are very easy to clean and there is no no risk of spillage or leakage.
FAST HYDRAULIC COUPLING
Fast hydraulic coupling of tractor and loader is made easy by compact design connections. For faster hydraulic connection, the ‘Quick Coupling’ or QC4 and QC6 multicouplers are available as an option.
HYDRAULIC IMPLEMENT LOCKING
Hydraulic implement locking is also available as an option. It offers higher comfort when attaching and detaching an implement by allowing the operator to stay in the cabin.
An optional set of LED worklights is available to give you maximum visibility at night. They’re perfectly integrated in to the beam and will provide maximum productivity and vision for longer working days.
Outward-facing grease points easily accessible and covered.
CONSISTENCY IN CONSTRUCTION
Robotised welding ensures consistency in construction throughout, whilst steel undergoes full preparation and priming before a tough and durable powder paint finish is applied.
SOFT DRIVE SUSPENSION
Stresses on loader and tractor, as well as the operator, can be reduced by the optional addition of the innovative SoftDrive® shock absorption system.
Lift Capacity to
|MF FL.3522||Non Self Leveling||140 (3550)||2,760 (1250)||MF 4700 Series|
|MF FL.3615||Mechanical Self Leveling||140 (3550)||3,420 (1550)||MF 4700 Series|
|MF FL.3723 8||Non Self Leveling||149 (3790)||2,840 (1290)||MF 5700 Series, MF 6700 Series|
|MF FL.3819||Mechanical Self Leveling||149 (3790)||4,230 (1920)||MF 5700 Series, MF 6700 Series|
|MF FL.4121||Mechanical Self Leveling||160 (4060)||2870 (1300)||MF 5S Series|
|MF FL.4124||Mechanical Self Leveling||160 (4060)||4370 (1980)||MF 6S Series|
|MF FL.4125||Non-Self Leveling||160 (4060)||2870 (1300)||MF 5S Series, MF 6S Series|
|MF FL.4227||Non Self Leveling||167 (4250)||3510 (1590)||MF 7S Series|
|MF FL.4327||Mechanical Self Leveling||167 (4250)||5450 (2470)||MF 7S Series|
|MF FL.4628||Mechanical Self Leveling||181 (4600)||5490 (2490)||MF 8S Series|
|MF FL.5033||Mechanical Self Leveling||195 (4960)||5710 (2590)||MF 8700S Series|
